Key Specifications
Brand / Manufacturer: Square D by Schneider Electric
Catalog Number: QOB360VH (with suffix options like QOB360VH1021 including an AC shunt trip)
Current Rating: 60 Amps
Number of Poles: 3-Pole (3P)
Voltage Rating: 120/240 VAC
Interrupting Rating (AIC): 22 kA at 120/240 VAC (High interrupting "VH" series)
Mounting Type: Bolt-on (designed for commercial NQ and NQOD panelboards)
Trip Type: Thermal-magnetic with VisiTrip trip indication
Wire Size: Accommodates 8 to 2 AWG aluminum or copper conductors
Terminal Torque: Box lugs tightened to 50 lb-in (5.6 N-m) — always verify the label on the physical unit
