Square D EDB34020 3 Pole 20 Amp 480Y/277V Type EDB Circuit Breaker

Schneider Electric / Square D Bolt-On Circuit Breaker Its Compact And Easy to Install Three poles thermal-magnetic circuit breaker has a current rating of 20 Amps at 40 deg c and voltage rating of 120/240/277 Vac it has an interrupt current rating of 25 Kiloampere At 120/240 Vac it accommodates aluminum/copper wire of size 14 to 6 Awg miniature circuit breaker has mounting bolts to hold the breaker in place circuit breaker is Ul listed and Csa certified.

Specifications :
• Manufacturer : Schneider Electric / Square D
• Cat. No. : EDB34020
• Alternate Part No.: EDB-34020
• UPC : 785901875246
• Product Type : Bolt-On Circuit Breaker
• Branch
• Protection : Thermal Magnetic
• Number Of Poles : 3 Pole
• Voltage Rating : 120/240/277 VAC At 50/60 Hz
• 480 VAC Star/277 VAC At 50/60 Hz (UL/CSA Listed)
• Amperage : 20 Amps At 40 Deg C
• Interrupting Rating : 25 Kiloampere At 120/240 VAC
• 18 Kiloampere At 480 VAC Star/277 VAC Or 277 VAC
• Wire Size : 14 To 6 AWG (Aluminum/Copper)
• Bolt On Mounting
• Size : 2.94" W X 4.05" D X 5.66" H
• Used On Merchandised NF Panelboard
• EDB Model
• Frame Type E
• Approval Ul Csa Ce
• Authentic Schneider Electric / Square D Product
